Coachman Lusso I

General

The Coachman Lusso I ( Coachman Lusso 1 ) is the newest model in the Lusso range. This 4 berth, single axle model, features everything its big brother, the Lusso II has, but in a much more space conscious way. The Lusso I is eight-foot wide, has a retractable island bed and an end bathroom. The lounge has been designed with an L-shaped layout, whilst the kitchen area contains a lightweight free-standing dining table, ideal for relaxing or socialising with friends.

Video Tour of Coachman Lusso 1

Feature Highlights

• NEW 40 litre Onboard fresh water tank
• NEW kitchen splashback in ‘Marmo Bianco Matt’ with integrated smooth action mechanism Softrollo pleated blind with flyscreen
• NEW Flatbed ventilated Microwave oven with co-ordinating flush fitting acrylic housing unit in ‘Flannel’ Design
• NEW domestic style flexible chrome and black kitchen tap
• NEW Thetford N4142 137 litre electronic fridge freezer
• NEW contemporary matt black furniture handles and push button catches
• Dovetail joints and NEW runners to all drawer units with soft close hinges
• 5G ready Wi-Fi

Virtual 360 Degrees Tour

Exterior Features

• European Whole Vehicle Type Approved ( EWVTA )
• EN1645 Grade 3 classification for heating and insulation – cold chamber tested
• 8ft wide automotive style, fully bonded aerodynamic body shell
• AL-KO, galvanised steel chassis with euro axle, overrun device and easy action handbrake
• Screwless, fully bonded awning rail to both sides
• 25mm aluminium sandwich sidewall construction with polystyrene insulation core
• 25mm sandwich construction roof for added strength and insulation
• 45mm sandwich construction floor with internal bracing for added strength
• 13 pin car ‘Jaeger’ connector
• 8ft wide ABS front panel incorporating, integral grab handles, fixed panoramic roof window, 3 flush fitting opening front windows and dual integrated front lockers for gas and storage with gas strut retainers
• 8ft wide ABS rear panel with white integral grab handles, high level brake light and light clusters
• Contrast colour step-on hitch cover with tread plates for easy cleaning of front windows
• E & P Self levelling system with control panel
• 10 spoke, hyper silver ‘Falcon’ alloy wheels and mud flaps
• Underslung AL-KO spare wheel carrier complete with steel spare wheel
• Mobile waste water carrier
• NEW Full length exterior graphics with front graphics
• Shock absorbers for smoother towing
• 100 watt roof mounted solar panel
• LED awning light and off-side services light
• Additional under bed access locker
• Whale exterior cold shower
• Whale external gas BBQ point with Easi-Slide lid
• Whale 230 volt external mains socket with Easi-Slide lid
• Exterior access battery box with mains electric inlet and external satellite and aerial connections
• Seitz superior one piece exterior door with high security locking system and easy action flyscreen
• Entrance step
• Whale bulkhead mounted gas regulator for use with butane or propane gas bottles, supplied with flexible hose for propane

Interior Features

• Smooth action mechanism Softrollo pleated blinds with flyscreens to all windows
• Luxury voile panel to the bedroom window
• Premium high quality fabrics
• Spacious L – Shaped front lounge seating
• NEW Superior sprung upholstery with co-ordinating scatter cushions, higher and more supportive backrests and armrests
• Luxurious mattress on the fixed bed
• Retractable fixed bed giving even more freedom to walk around
• Concertina room divider between the kitchen & bedroom area
• Domestic floor covering in ‘French Oak-Dark Grey’ design
• Unique Wood colour scheme
• Luxurious deep pile stain resistant loose lay carpets
• Contemporary two toned cranked style locker doors in ‘Morrisette and Sand’ to the lounge and bedroom with soft close hinges
• NEW soft close hinges to all base unit doors
• Overhead locker profile in ‘graphite’ design with decorative silver trim and LED layered lighting
• LED layered lighting
• Centre console in ‘graphite’ design with integrated down lighting
• NEW contemporary matt black furniture handles and push button catches
• Dovetail joints and NEW runners to all drawer units with soft close hinges
• Colour co-ordinated sockets and switches with chrome surrounds
• Easy action aluminium framed sliding front bed make up mechanism
• Easy access aluminium lift up bed frames, gas strut supported with sprung beech slats
• Lightweight free standing table with dedicated storage area
• Seating and bed ventilation boards throughout
• Removable entrance mat with tray
• Shelving in selected overhead lockers
• Roof light to front lounge and fixed bed areas

Kitchen Features

• Under locker integrated extractor fan
• L-Shape designed kitchen with increased workspace and deeper cupboards
• NEW kitchen splashback in ‘Marmo Bianco Matt’with integrated smooth action mechanism Softrollo pleated blind with flyscreen
• Thetford round stainless steel underslung sink with worktop/flush fitting bowl infill
• NEW Flatbed ventilated Microwave oven with co-ordinating flush fitting acrylic housing unit in ‘Flannel’ Design
• NEW domestic style flexible chrome and black kitchen tap
• Kitchen splashback in ‘Palladio’ design
• Composite kitchen worktops in ‘Silver Pebble’ design finish with rear upstand
• Larger lift up kitchen worktop extension
• Thetford dual fuel hob with cast iron pan rest, electronic ignition, glass lid and flame failure device
• Thetford fan assisted oven has an interior light and separate grill with chrome finish and improved efficiency
• LED touch sensitive dimmable under surface and locker ambience enhancing lighting
• ‘Bianca’ acrylic glass kitchen locker doors with domestic soft close hinges
• Positive catches to main kitchen drawers
• Deep pull out chrome baskets to lower kitchen cupboards
• NEW Thetford N4142 137 litre electronic fridge freezer

Audio and Entertainment

• DAB Radio
• Entertainment speakers in lounge and bedroom areas
• Dedicated TV station with 230v, 12v, satellite and aerial sockets
• Dedicated TV station with 230v, 12v, and aerial sockets in fixed bed areas
• NEW Double USB socket and ‘C’ Port socket situated at the main dedicated TV station
• NEW Integral USB socket in the spotlights to all areas
• Wireless mobile phone charging unit ( integrated into the bulkhead ) suitable for iPhone 8 & Samsung 7 and above
• NEW Teleco Teleplus TV aerial with integrated FM/DAB reception capability
• 5G ready Wi-Fi

Electrical Features

• NEW Multi directional matt black LED reading spot lights with USB ports to all areas
• NEW Matt black LED down lighter spot lights
• 100% low energy LED lighting throughout
• Floor level courtesy lighting
• Alde load limiter
• Mains connection lead ( 25m )
• 12 volt system ( 20 Amp ) with battery charger and mains transformer
• 12 volt ‘Seattle’ multi-function digital control panel with awning light, water pump, water tank, 12v lights and master switches

Plumbing and Heating

• Alde wet central heating and hot water system with 5 year Glycol, 3030 boiler with integrated pump and programmable LCD touch screen control panel

Alde's wet central heating system has been meticulously planned and installed to ensure you always enjoy the optimum temperature throughout your caravan.

The radiant, hydronic central heating offers many benefits:

1. It heats every part of the caravan creating a warm and inviting environment
2. The glycol heating fluid circulates quietly around your caravan ensuring the least amount of disturbance
3. It works off both gas and electric power sources which, can be combined when required
4. Low 12V battery consumes a low amount of energy, preserving your battery life
5. Pipes and radiators are mounted discreetly behind furniture, optimising available storage

• NEW Dometic Fresh-Jet FJX4 2200 air conditioning system with integrated heat pump
• Alde Flow continuous hot water system
• Whale Water Master mains connection
• Whale Watermaster inlet point – intelligent control with high flow submersible pump
• NEW 40 litre Onboard fresh water tank

Safety and Security Features

• AL-KO ( ATC2 ) Trailer Control System - Anyone who has ever encountered critical driving situations when towing their caravan will know that the caravan reacts very sensitively at high speeds – and what the risks are! Even minor avoidance manoeuvres, side winds on bridges or wind pressure when overtaking trucks can soon cause the trailer to start snaking. ATC AL-KO Trailer Control actively counteracts such phenomena!
• AL-KO AKS 3004 Stabiliser - Suppresses the initial signs of caravan instability and improves ride comfort. Four specially designed friction pads work to effectively suppress the initial signs of caravan instability and snaking movements, providing excellent ride comfort for your car and caravan combination.
• AL-KO secure wheel lock
• Phantom VanGuard remote control alarm system with PIR and tilt sensors for added security  ( fob controls the awning light )
• Optical smoke alarm
• Carbon monoxide detector
• CRIS ID number and concealed security data ID chips
• High security one key locking system supplied with 2 flip keys
• Dometic safe

Coachman Lusso 1 Specifications

• Berths: 4
• Axle Type: Single Axle
• Interior Length: 5800mm / 19' 0"
• Overall Length: 7430mm / 24' 5"
• Overall Width: 2440mm / 8' 0"
• Overall Height ( including T.V Aerial ): 2675 mm / 8 ' 9 "
• Overall Height ( including Air Conditioning ): 2750mm / 9’ 0”
• Maximum Headroom: 1955 mm / 6 ' 5 "
• MTPLM: 1836 kg
• Mass in Running Order: 1681 kg
• Personal Payload: 155 kg
• Bed Sizes:
  Front Double -  6’ 6” x 4’ 6” ( 1980mm x 1370mm )
  Rear Fixed Double - 6’ 2” x 4’ 6” ( 1875mm x 1370mm )
